| ■主な仕様 | SENSOR TYPE : V-RAPTOR(R) XE 8K VV 35.4MP Global Shutter CMOS
EFFECTIVE PIXELS : 8192 x 4320
SENSOR SIZE : 40.96 mm x 21.60 mm (Diagonal: 46.31 mm)
DYNAMIC RANGE : 17+ stops
MOUNT TYPE : Integrated locking Z mount with electronic communication
Supports /i PL lenses with RED Z to PL Adapters
Supports Nikon FTZ II Adapter with communication and other adapters based on the Nikon Z mount
MAX DATA RATES : Up to 800 MB/s using RED branded or other qualified CFexpress media cards1
REDCODE(R) RAW MAX FRAME RATES :
60fps at 8K 17:9, 75 fps at 8K 2.4:1
70 fps at 7K 17:9, 87 fps at 7K 2.4:1
80 fps at 6K 17:9, 100 fps at 6K 2.4:1
96 fps at 5K 17:9, 120 fps at 5K 2.4:1
120 fps at 4K 17:9, 150 fps at 4K 2.4:1
160 fps at 3K 17:9, 200 fps at 3K 2.4:1
240 fps at 2K 17:9, 300 fps at 2K 2.4:1
BEST AVAILABLE REDCODE(R) SETTINGS :
REDCODE HQ, MQ, LQ, and ELQ at 8K 17:9 up to 60 fps
REDCODE HQ, MQ, LQ, and ELQ at 6K 17:9 up to 80 fps
REDCODE HQ, MQ, LQ, and ELQ at 4K 17:9 up to 120 fps
REDCODE HQ, MQ, LQ, and ELQ at 2K 17:9 up to 240 fps
REDCODE(R) RAW
ACQUISITION FORMATS : 8K 17:9, 2:1, 2.4:1, 16:9, 1:1 and Anamorphic 2x, 1.8x, 1.6x, 1.5x, 1.3x, 1.25x
7K 17:9, 2:1, 2.4:1, 16:9, 1:1 and Anamorphic 2x, 1.8x, 1.6x
6K 17:9, 2:1, 2.4:1, 16:9, 1:1 and Anamorphic 1.5x, 1.3x, 1.25x
5K 17:9, 2:1, 2.4:1, 16:9, 1:1
4K 17:9, 2:1, 2.4:1, 16:9, 1:1
3K 17:9, 2:1, 2.4:1, 16:9, 1:1
2K 17:9, 2:1, 2.4:1, 16:9, 1:1
APPLE PRORES :
Dedicated recording in ProRes 4444 XQ, ProRes 4444, ProRes 422 HQ, ProRes 422, and ProRes 422 LT at resolutions up to 4K (4096x2160) 120P
Proxy recording available up to ProRes 422 HQ in 2K (2048 x 1080) up to 60P.
CONSTRUCTION : Aluminum Alloy
DIMENSIONS : 149.63 mm x 115.5 mm x 108 mm / 5.9 in. x 4.5 in. x 4.3 in. (LxWxH, largest fixed dims.)
WEIGHT : 4.03 lbs / 1.83 kg (without body cap and CFexpress card)
MEDIA TYPE : CFexpress Type B
BATTERY TYPE : Integrated V-Lock battery interface optimized for Micro V-Lock Batteries1
DC POWER INPUT : 11-17 V via 6-Pin DC-IN
OPERATING TEMPERATURE : 0°C to 40°C (32°F to 104°F)
STORAGE TEMPERATURE : –20°C to 50°C (–4°F to 122°F)
STORAGE RELATIVE HUMIDITY : 0% to 85% non-condensing
COLOR MANAGEMENT :
Image Processing Pipeline 2 (IPP2)
Supports 33×33×33 3D LUTs
Supports import and adjustment of CDLs
AUDIO :
Integrated dual channel digital mono microphones, uncompressed, 24-bit 48 kHz
Integrated dual channel (mic/line/+48V) input via 5-Pin 00B Audio Port, uncompressed, 24-bit 48 kHz
3.5mm stereo headphone port
AUTOFOCUS : Phase Detect with Face Detection
IP CONNECTED : Dual band Wi-Fi (2.4 GHz or 5 GHz) for wireless camera control, live preview, and direct Camera to Cloud workflow via FrameIO or Amazon S3
Wired control via USB-C or Ethernet (compatible USB-C to Ethernet adapter1 required) for remote camera control, live preview, direct Camera to Cloud workflow and high speed remote media offload
Compatible with optional RED Connect license for live 8K R3D video over USB-C to Ethernet adapter
MONITOR OUTPUTS :
Proprietary Top Accessory Port for Monitoring and Control
Integrated dual 12G-SDI with 6G-SDI, 3G-SDI and 1.5G-SDI modes
12G-SDI: Up to 4096 x 2160 4:2:2 for 60p
6G-SDI: Up to 4096 x 2160 4:2:2 for 30p, 25p, 24p
3G-SDI: Up to 2048 x 1080 4:2:2 for 60p
1.5G-SDI: Up to 2048 x 1080 4:2:2 for 30p, 25p, 24p
SMPTE Timecode, HANC Metadata, 24-bit 48 kHz Audio
MONITOR OPTIONS : DSMC3 RED Touch 7.0” LCD
RED Compact EVF with DSMC3 Adapter A
Wireless 1080p live preview video feed via 2.4Ghz/5Ghz Wi-Fi for framing
Integrated 2.4" LCD for camera control (no preview video)
ADDITIONAL I/O :
Tri-Level Genlock Input via 9-Pin EXT
LTC Timecode Input via 9-Pin EXT
RS232 CTRL (using RCP2) via 9-Pin EXT
RED CONTROL & RED CONTROL PRO : Access full camera controls and live preview from iOS or Android devices
Pro App: Operate one or multiple cameras over an IP connection to synchronize settings, manage media files locally or upload directly to FrameIO, develop custom looks with advanced CDL and LUT controls, and more. Ideal for control of multi-camera arrays, multi-cam shoots, and live events, all from one central location.
Standard app available from the Apple App Store and Google Play Store.
RED Control Pro available via Apple App store only and requires additional purchase.
RED Control works wirelessly or wired via USB-C
Tech specs reflect both current and projected information. Everything is subject to change. |
|---|
